AT40

0 VNĐ
Trước Thuế: 0 VNĐ

Mã sản phẩm: AT40
Tình trạng: Còn hàng

Số lượng: + -

Thêm Yêu thích Thêm so sánh

Mô tả Đánh giá (0)

AT40

Features

720p
Transmission mwithout lossless
Distance up mto 500 meters
No delay
Easy to implement

Model	WAHD10E-AT40	WAHD100-AT40
Pick up Element	1/4" CMOS 1004	1/4" CMOS OV 9712
Effective Picture Elements (H×V)	PAL/NTSC : 1280*720	PAL/NTSC : 1280*720
Horizontal Resolution	1280H	1280H
Minimum Illumination	0.2 Lux	0.01 Lux
	0Lux (with IR LED ON)	0Lux (with IR LED ON)
S/N Ratio	More than 41dB	More than 69dB
Scanning System	2:1 interface
Synchronous System	Internal, Negative sync.
Auto Electronic Shutter	1/50(1/60)S-1/100,000S
Gama Characteristic	0.45
IR Distance	40Meters (with ￠5X42PCS Infrared LED)
IR Status	Under 10Lux by CDS
IR Power On	CDS AUTO Control
Video Output	1Vpp, 75Ω
Auto Gain Control	Auto
Power/Current	DC12V/550mA ±10%
Lens	2.8-12mm (2Megapixel)
	Manual Zoom Lens
Dimension (mm)	200(W)x171(H)x83(D)mm
Storage Temperature	-30~+60℃ RH95% MAX
Operating Temperature	-10~+60℃ RH95% MAX
