Loop-O9550-C SDH/SONET

0 VNĐ
Trước Thuế: 0 VNĐ

Mã sản phẩm: Loop-O9550-C SDH/SONET
Tình trạng: Còn hàng

Số lượng: + -

The O9550-C has capacity for 5 single slots and 4 mini plug-in slots. The O9550-C supports up to 252 E1 or 336 T1 in a STM-4/OC-12 ring, and a maximum of 36 E1 or 24 T1 in the tributary interfaces, which added together can reach 288 E1 or 360 T1 for non-blocking DS0 cross connect.

Full front access (ETSI) shelf
ADM, TM, and cross-connect
Per chassis single STM-1/4 (OC-3/12) optical ring uplinks
- Up to four STM-1/4 (OC-3/12) aggregate lines that are software configurable
- Non-blocking N x 64 Kbps for 252 E1 or 336 T1 for data and voice channel transmission for uplink site
Tributary modules (see plug-in cards for detail)
Power Modules:
- DC Module: (-48Vdc)
- AC Module: AC(100V~240V)
- Dual Power: (1+1) Protection for DC only
SSM and CLK hold over function (SDH/SONET and E1/T1)
Controller protection:
- MSP (1+1) or SNCP for single controllers
- MSP (1+1) and SNCP for dual controllers
E1/T1/FOM support 1+1 and 1:1 Line protection
A-law to µ-law conversion
Alarm in/out, clock in/out
Support E1/T1/FOM ring structure
Support E1 DS0 SNCP ring
Compatible to a SNMP based GUI network management system and supported by LoopView and Loop iNMS
SSH V2
SNMP V1 and V3
RoHS compliant
